Creating a Hosting session with a couple users is usually not really hard but it can become really tricky when you start being more than 4 pilots on the Hosting server with limited bandwidth.

So how do we handle the network settings and how do we make sure your BMS experience is great?

Understanding the Network settings

 The ports NAT/PAT settings

For BMS Server you need the following settings on your router (internet box):

  • Rule Name: “BMS Server”
  • Protocol: UDP
  • Internal ports range: 2934-2935
  • External ports range: 2934-2935
  • Source: ALL (0.0.0.0/0)
  • Destination: Your BMS server local IP

For IVC Server you need the following settings on your router (internet box):

  • Rule Name: “IVC Server”
  • Protocol: UDP
  • Internal ports range:9987-9989
  • External ports range:9987-9989
  • Source: ALL (0.0.0.0/0)
  • Destination: Your IVC server local IP

If you need to test your UDP connectivity on the Falcon BMS side, you can try this tool F4testPort (this tool is provided as is and not supported by us…)

The Bandwidth settings

This section is really key to start troubleshooting your connection troubles…

Right now, Falcon BMS requires at least 2048 Kbit/s to secure a single client feedback. So if your upload bandwidth is lower than that, consider dealing with issues or start thinking about upgrading your ISP…

If you are lucky and have more than 2M upload, then set it to Max 70% of your upload capacity… Use speedtest.net if you need to check that!

The Falcon BMS config file

There are some hidden settings in the Falcon BMS code that can tweak the way clients and servers communicate together…

In the “Falcon BMS.cfg” file (/user/Config/) you will find the following settings:

set g_bServerHostAll

This setting must remain to 1 if you wish your MP session to maintain data consistency since all datas impacting the TA / Campaign are sent to server to be redistributed to other clients.

set g_nForceMinClientBwSetting

As you should have understood by now, this setting should be at a minimum of 2048 to ensure client good transmission rate…

set g_bHostAllowsDubiousConnections

As a host, especially if you have an online 24/7 server, it is recommended to avoid dubious connections. Make sure you have this setting to 0.

set g_bHostDisableP2pForDubiousConnections

If you have set previous setting to 1. You can make sure those clients are not using P2P and connect only to server (might avoid latency issues)

Configuring your MP session

On server side

Should have at least 2048Kbit/s per client connected. So if 20 clients: 20 x 2048 = 40960 Kbit/s…

Make sure you don’t use more than 70% of your line capacity or the side effects with line saturation might become a show stopper.

You will also need to make sure that all the clients will respect the following settings for clients (see below).

On client side

Upload

Make sure you don’t have more than 70% of your upload settings is used.

If you have an upload of less than 1024… It might be difficult to connect to online connection…

Download

Same thing applies as for upload. Make sure you don’t use more than 70% of available bandwidth.

Conclusion

There are some simple rules to apply to at least make sure connectivity experience is best. There will be some other articles on tools that help you on connectivity…

Meanwhile, the last tip I could give you is make sure your TE is not too heavy in troops movements since load on CPU will be high as well as network traffic activity…

This does not guaranty a 100% success rate but with those rules and high player load, you should be pretty safe! 🙂

Enjoy your falcon flights!
